Displacement

X-axis (spindle right/left): 600mm
Y-axis (table front and back): 400mm
Z-axis (spindle up/down): 350mm
U-axis (left and right) : 150mm
V-axis (front and rear) : 150mm

Processing tank internal dimensions


1050mm×710mm

 Table

Maximum workpiece dimensions: 800mm×570mm×280mm
Maximum loading weight : 850kg

Wire electrode

Electrode diameter: 0.05 to 0.3 mm
Wire tension : 3 to 23N

Feeding speed

 Maximum wire feed speed: 420mm/min
